Home › Leviton 1242-W 15 A 120/277 VAC Wall Plate White
Leviton 1242-W 15 A 120/277 VAC Wall Plate White
Model / SKU: 1242-W · UPC 07847733033$13.99
$13.99 each
Spec Sheet & Documents
Download Spec Sheet (PDF)- 🚚 Free shipping on orders $999+
- ↩ Easy returns
| Part Number | 1242-W |
| UPC | 07847733033 |
| HP Rating | 1/2HP-120V 2HP-240V-277V |
| Amperage | 15 A |
| Current Interrupting | Certified for current interrupting at full rated current |
| Dielectric Voltage Withstand | 1500V minimum |
| Grounding | Self-Grounding |
| Max. Amperage | 12 Amp |
| Maximum Working Voltage | 120/277 VAC as rated |
| Temperature Rise | Maximum 30 degress C rise |
| Voltage | 120/277 VAC |
| Flammability | Rated V-2 per UL 94 |
| Operating Temperature | -40°C to 65°C |
| Actuator Material | Thermoplastic |
| Base Material | Urea |
| Body Material | Thermoplastic |
| Color | White |
| Contacts | Silver-Cadmium .031 Thick |
| Cover Material | Urea |
| Grounding Leads | 6", #12 AWG THHN |
Commercial%20Industrial%20Switch%20Brochure%20Q-1223A%20AUG23v1.pdf
Commercial-Industrial-Switch-Brochure-Q-1223-FR-CAD.pdf
| Brand | Leviton |
| SKU | 1242-W |
| UPC | 07847733033 |
| Type | Wall Plates |
