Leviton 1243-I 20 A 120/277 VAC Wall Plate Ivory
Model / SKU: 1243-I · UPC 07847733383$15.27
$15.27 each
Spec Sheet & Documents
Download Spec Sheet (PDF)- 🚚 Free shipping on orders $999+
- ↩ 30-day returns (see policy)
| Part Number | 1243-I |
| UPC | 07847733383 |
| HP Rating | 1/2HP-120V 2HP-240V-277V |
| Amperage | 20 A |
| Current Interrupting | Certified for current interrupting at full rated current |
| Dielectric Voltage Withstand | 1500V minimum |
| Grounding | Self-Grounding |
| Max. Amperage | 12 Amp |
| Maximum Working Voltage | 120/277 VAC as rated |
| Temperature Rise | Maximum 30 degress C rise |
| Voltage | 120/277 VAC |
| Flammability | Rated V-2 per UL 94 |
| Operating Temperature | -40°C to 65°C |
| Actuator Material | Thermoplastic |
| Base Material | Urea |
| Body Material | Thermoplastic |
| Color | Ivory |
| Contacts | Silver-Cadmium .031 Thick |
| Cover Material | Urea |
| Grounding Leads | 6", #12 AWG THHN |
Commercial%20Industrial%20Switch%20Brochure%20Q-1223A%20AUG23v1.pdf
Leaded%20Receptacles,%20GFCIs%20and%20Switches%20Product%20Bulletin%20Q-1133A.pdf
| Brand | Leviton |
| SKU | 1243-I |
| UPC | 07847733383 |
| Type | Wall Plates |
| Title | Default Title |
Free ground shipping on orders over $999. Orders ship direct from the manufacturer or distributor warehouse, typically within 2–5 business days, then 2–7 business days in transit. Contiguous U.S. only. Freight orders are quoted before you are charged. See our shipping policy and 30-day return policy.
