Home › Leviton 1BH42-N Wall Plate Green
Leviton 1BH42-N Wall Plate Green
Model / SKU: 1BH42-N · UPC 07847700538$1,431.23
$1,431.23 each
Spec Sheet & Documents
Download Spec Sheet (PDF)- 🚚 Free shipping on orders $999+
- ↩ Easy returns
| Part Number | 1BH42-N |
| UPC | 07847700538 |
| Max. Amperage | 20A Max |
| Construction | Welded pedestal body and cover with removable access panel and wire entry slots |
| Grounding | Stainless Steel (Pre-installed Lug) |
| Pedestal Material | 304 Stainless Steel (14 gauge body, cover and access panel) |
| Conduit Feeds | Accommodates two 1-1/2" conduit raceways |
| Height | 42" inch (18" above grade) |
| Maximum Dimensions | 42.0"H x 2.75"W x 6.0"D |
| Mounting Plate | 1-Gang Decora |
| Application | Commercial,RV/Campsites |
| Base | Direct Bury |
| Color | Green |
| Hinge Type | Standard |
| Receptacle Compatibility | Decora Style |
| Top | Lockable Hinged Top |
| Certification/Listing | cULus |
| Warranty | 1-Year Limited |
| Brand | Leviton |
| SKU | 1BH42-N |
| UPC | 07847700538 |
| Type | Wall Plates |
| Title | Default Title |
