Home › Leviton 5029-W 15 A 250 VAC Wall Plate White
Leviton 5029-W 15 A 250 VAC Wall Plate White
Model / SKU: 5029-W · UPC 06867912334$4.68
$4.68 each
Spec Sheet & Documents
Download Spec Sheet (PDF)- 🚚 Free shipping on orders $999+
- ↩ Easy returns
| Part Number | 5029-W |
| UPC | 06867912334 |
| Nema | 6-15R |
| RoHS Compliant | Yes |
| At Rated Voltage | 1-1/2 HP |
| Amperage | 15 A |
| Current Limiting | Full Rated Current |
| Dielectric Voltage | Withstands 2000V per UL498 |
| Pole | 2 |
| Temperature Rise | Max 30C after 100 cycles OL at 150 percent rated current |
| Voltage | 250 VAC |
| Wire | 3 |
| Flammability | Rated V-2 per UL 94 |
| Operating Temperature | -40°C to 60°C |
| Body Material | Nylon |
| Color | White |
| Face Material | Nylon |
| Grounding Screw | Brass 8-32 |
| Line Contacts | Brass Triple Wipe .031 Thick |
| Strap Material | Zinc-Plated Steel |
| Brand | Leviton |
| SKU | 5029-W |
| UPC | 06867912334 |
| Type | Wall Plates |
| Title | Default Title |
