Leviton 54501-2W 15 A 120/277 VAC Wall Plate White
Model / SKU: 54501-2W · UPC 07847712576$3.89
$3.89 each
Spec Sheet & Documents
Download Spec Sheet (PDF)- 🚚 Free shipping on orders $999+
- ↩ Easy returns
| Part Number | 54501-2W |
| UPC | 07847712576 |
| HP Rating | 1/2HP-120V 2HP-240V-277V |
| Amperage | 15 A |
| Dielectric Voltage | Withstands 1500V for 1 minute |
| Max. Amperage | 12 Amp |
| Temperature Rise | Maximum 30 degrees C rise |
| Voltage | 120/277 VAC |
| Flammability | Rated V-2 per UL 94 |
| Operating Temperature | -40°C to 65°C |
| Actuator Material | Thermoplastic |
| Base Material | PBT |
| Body Material | Thermoplastic |
| Color | White |
| Contacts | Silver-Cadmium .031 Thick |
| Cover Material | Nylon |
| Strap Material | Steel |
| Terminal Screws | Steel 8-32 |
| Toggle | Polycarbonate |
| Product ID | Stamped on Strap |
Commercial%20Industrial%20Switch%20Brochure%20Q-1223A%20AUG23v1.pdf
Commercial-Industrial-Switch-Brochure-Q-1223-FR-CAD.pdf
| Brand | Leviton |
| SKU | 54501-2W |
| UPC | 07847712576 |
| Type | Wall Plates |
