Leviton 5801-W 20 A 125 VAC Wall Plate White
Model / SKU: 5801-W · UPC 07847724920$4.10
$4.10 each
Spec Sheet & Documents
Download Spec Sheet (PDF)- 🚚 Free shipping on orders $999+
- ↩ 30-day returns (see policy)
| Part Number | 5801-W |
| UPC | 07847724920 |
| Nema | 5-20R |
| RoHS Compliant | Yes |
| At Rated Voltage | 1 HP |
| Amperage | 20 A |
| Current Limiting | Full Rated Current |
| Dielectric Voltage | Withstands 2000V per UL498 |
| Grounding | Grounding |
| Pole | 2 |
| Temperature Rise | Max 30C after 100 cycles OL at 150 percent rated current |
| Voltage | 125 VAC |
| Wire | 3 |
| Flammability | Rated V-2 per UL 94 |
| Operating Temperature | -40°C to 60°C |
| Body Material | Nylon |
| Color | White |
| Face Material | Nylon |
| Grounding Screw | Brass 8-32 |
| Line Contacts | Brass Double Wipe .031 Thick |
Straight%20Blade%20Receptacle%20Catalog%20Q-1101H.pdf
- Certifications & Listings: UL Listed
| Brand | Leviton |
| SKU | 5801-W |
| UPC | 07847724920 |
| Type | Wall Plates |
| Title | Default Title |
