Leviton AFTR1-HGW 15 A & 20 A Feed-Through 125 VAC GFCI Receptacle White
Model / SKU: AFTR1-HGW · UPC 07847769214$49.12
$49.12 each
Spec Sheet & Documents
Download Spec Sheet (PDF)- 🚚 Free shipping on orders $999+
- ↩ 30-day returns (see policy)
| Part Number | AFTR1-HGW |
| UPC | 07847769214 |
| At Rated Voltage | 1 HP |
| Amperage | 15 A & 20 A Feed-Through |
| Dielectric Voltage | Withstands 2000V per UL498 |
| Grounding | Self-Grounding |
| Pole | 2 |
| Temperature Rise | Max 30C after 250 cycles OL at 200 percent rated current |
| Voltage | 125 VAC |
| Wire | 3 |
| Flammability | Rated V-0 per UL 94 |
| Operating Temperature | -35C to +66C |
| Body Material | Polycarbonate |
| Face Material | PBT |
| Ground Clips | Brass |
| Grounding Screw | Plated Steel |
| Line Contacts | Brass Double Wipe .031 Thick |
| Strap Material | Zinc-Plated Steel |
| Terminal Clamp | Plated Steel |
| Terminal Screws | Plated Steel |
Q-896%20HG%20AFCI%20PB%20Reset.pdf
- Certifications & Listings: UL Listed
| Brand | Leviton |
| SKU | AFTR1-HGW |
| UPC | 07847769214 |
| Type | GFCI Receptacles |
| Title | Default Title |
