Home › Leviton OSM3D-V1W Occupancy Sensor, Microwave, Surface Mount, 120-277V, 1664SF, White
Leviton OSM3D-V1W Occupancy Sensor, Microwave, Surface Mount, 120-277V, 1664SF, White
Model / SKU: OSM3D-V1W · UPC 07847766061$79.49
$79.49 each
Spec Sheet & Documents
Download Spec Sheet (PDF)- 🚚 Free shipping on orders $999+
- ↩ 30-day returns (see policy)
Occupancy Sensor, Microwave, Surface Mount, 120-277V, 1664SF, White
| Part Number | OSM3D-V1W |
| UPC | 07847766061 |
| RoHS Compliant | Yes |
| Frequency | 50/60Hz |
| Load Rating | Tungsten: 800 W @ 120VAC, Electronic Driver/Ballast: 1000VA @ 120VAC, Driver: 1200VA @ 277VAC |
| Neutral Wire Connection | Required |
| Power Consumption | ≤0.5W (standby) - <1W (operation) |
| Voltage | 120-277 VAC |
| Relative Humidity | 20% to 90% non-condensing |
| IP Rating | IP20 |
| Mounting Type | Surface Mount or Base Mount |
| Size | Height 3.2" (82mm), Width 1.73" (44mm), Depth 1.05" (26.84mm) |
| Coverage (Sq.Ft.) | 1664.0 |
| Foot Candle Level | 0.46FC (5lux)/1.39FC (15lux)/2.78FC (30lux)/4.64FC(50lux)/disable |
| Pattern | Wall: 150° Ceiling: 360° |
| Application | Garages, Warehouses, Metal Walls or Fixtures Including Wall Sconces and Wall Packs |
| Color | White |
| Grade | Commercial |
| Mounting | Surface Mount or Base Mount |
| Mounting Height (Ft.) | Up to 32 FT |
High-Frequency-Microwave-Occupancy%20Sensor-OSM3D-V1W-English-Data-Sheet.pdf
LES-G-10676-IP%20Ratings%20and%20UL%20Listings.pdf
- Certifications & Listings: UL Listed, IP20
| Brand | Leviton |
| SKU | OSM3D-V1W |
| UPC | 07847766061 |
| Type | Occupancy Sensors |
